• Europen type sectioned punch holder
• Europen type sectioned die holder
• Esa S 630 control unit
• 4 Axis – Y1, Y2, X, R
• Side and back safety gates
• DSP Laser front protection system with CE norm
• Foot pedal with emergency stop button
• 380 V, 50-60 HZ, 3Ph Electrical system
• Electrical Cabinet Cooling System
• Delem DA 66T Control unit
• Delem DA 69T 3D Control unit
• Fiessler Akas 2 M(P) protection system
• Light curtain with CE norm
• Pneumatic tool holding system
• Wila mechanic Tool Holding System
• Wila hydraulic Tool Holding System
Bending Length: 600 mm
Bending Capacity: 20 ton
Maximum Stroke: 140 mm
Daylight Opening: 415 mm
Approaching Speed: 150 mm/s
Bending Speed: 20 mm/s
Return Speed: 150 mm/s
Main Motor: 3.8 kW
Weight: 1700 kg
Overall Length: 1250 mm
Width: 1410 mm
Height: 2200 mm
Bending Length: 900 mm
Bending Capacity: 20 ton
Maximum Stroke: 130 mm
Daylight Opening: 325 mm
Approaching Speed: 150 mm/s
Bending Speed: 20 mm/s
Return Speed: 150 mm/s
Main Motor: 3.8 kW
Weight: 1800 kg
Overall Length: 1250 mm
Width: 1710 mm
Height: 2200 mm
Bending Length: 1300 mm
Bending Capacity: 40 ton
Maximum Stroke: 150 mm
Daylight Opening: 350 mm
Approaching Speed: 150 mm/s
Bending Speed: 20 mm/s
Return Speed: 150 mm/s
Main Motor: 3.8 x 2 kW
Weight: 3500 kg
Overall Length: 1700 mm
Width: 2200 mm
Height: 2300 mm
